SS05
SS05
SS05SS05SS05SS05
Code:SS05
Description

Requiring access only to the power of the sun, our wireless systems offer a simple and cost-effective alternative for illuminating fences, walls and borders that can be located a long distance from established electrical and communications equipment. We've combined our proprietary solar with state of the art Cree LED luminaires to offer unparalleled reliability and excellent lumens-per-watt brightness throughout the year and in all weather conditions. Our tamper resistant designs also have no external cabling and offer high-mounted solar engines and controllers to proctect the light from all but the most persistent vandal. Each solar light acts independently of others in a network so tampering with one light will never impact other lights in a system.

Components

Parameters

Solar Module

Pmax(W)

30-320W solar panel

Vmp (V)

18V or 35.5V

Imp (A)

From 1.67A to 9A

Light Fixture

Material

Aluminum die casting & Toughened glass

Operating Temperature

-40°C~75°C

Protection Level

IP65 rate for led solar street light

LED Light Source

LED Chip

BRIDGELUX or Cree

Color Temperature

3800-6500K(warm white/pure white)

Luminous flux

5300 LM led solar street light

Operating temperature

-40°C~75°C

Current Source

DC 12V/24V

Power

15W/18W/21W/24W/30W/36W/42W/48W/54W/60W/80W

Lighting Pole

Height

3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m

Material

Q235/345/GR60

Surface Treatment

Hot-dip galvanizing, Static spray for led solar street light

Size

φ60-φ200,δ3-5m, vary according to models

Flange Plate

300*300*16, vary according to models

Battery

Capacity

200AH (100AH*2pcs)

Type

Gel/AGM Battery

Dimension

546*1203*30

Weight

28Kg, varying with different led solar street lights

Controller

Rated voltage and current

12V/10A or 24V/10A waterproof

Weight

0.165Kg

Two times rainy day backup

&Protective Function

Two times of rainy day backup.

Good protection: overcharging, discharging, voltage surge, reverse polarity, etc.

Accessories

Cable

2.5 mm2, 15m

Battery Box

200AH ABS battery box or metal box with hot-dip galvanizing spray treatment

Foundation Kit

Dismountable foundation kit, saving in shipping
